Description

• Advanced dual-core DSP control technology
• True On-line, double conversion power protection, and with strong load capacity
• Compact footprint, modular Hot-swappable design simplifying maintenance and scalability
• High efficiency up to 96% in on-line mode, 99% efficiency in ECO mode
• Dual input design, independent bypass available, improving bypass availability
• Output power factor 1.0, input power factor ≥ 0.99, input THDi ≤ 3%, output THDv ≤ 2%
• 114 ~ 277 Vac wide input voltage range, 50 Hz / 60 Hz grid self-adaptive
• Frequency conversion available: 50 Hz input / 60 Hz output or 60 Hz input / 50 Hz output
• Advanced digital parallel technology, improving redundancy and reliability in system
• Flexible charger parameter and battery configuration settings, battery number 16 ~ 24 pcs selectable
• Compatible with lead-acid battery and lithium battery, suitable for different types of battery configuration requirements
• Support cold start with battery and auto restart with mains power
• Settable delay time for startup when the mains power is restored, reducing the impact on the grid or generators
• Fan speed varies intelligently with temperature, reducing noise and extending the service life of the fan
• Fault-tolerant design for fan system, taking 35% loads when any one of fans fails
• Superior hardware and software protection function, robust self-diagnostic function, and abundant event log
• Hibernation function to improve the system efficiency at light loads and extend the service life of UPS
• Powerful background software for parameters configuration and online updating
• 7 inches LCD touch screen, friendly human-machine interface
• Multi-platform communications: RS485, CAN, NET, dry contacts, SNMP, and Wi-Fi communication interfaces; Real-time monitoring UPS available through the mobile App after installing Wi-Fi card
• Intelligent battery management, automatic floating/equalizing charge control, battery self-diagnosis control, SOC detection, SOH detection and charger hibernation control, extending battery lifespan
